PV MOUNTING SYSTEM

Ground Mounted Solar PV Mounting System Structure

  • Flat Roof Bracket/Ground Bracket
  • Material: Aluminum Alloy/PosMAC
  • Slope: Any
  • Wind Load: 40-60m/s
  • 10years, 25years Service Life
  • Customized Design Service

Ground Mounted Solar PV Mounting System Structure


Ground Mounted Solar PV Mounting System are mainly made of SUS304 and AL6005-T5 material, and new material PosMAC is popular to use. The structure is consice, solid and at good look-appearance. The flat solar mounting structure is easy to assemble and at labor-cost save. The solar mounting system is applicable to a variety of rooftops and ground-mounted sites.






SPECIFICATIONS

  • Installation site:   Ground/Flat roof.
  • Installation angle:   5°,10°, customized
  • Wind speed:<50m/s.
  • Snow load: <1.2KN/m2.
  • Build height:<20m.
  • Material:AI 6063-T5 & SUS304./ PosMAC
  • Surface treatment: Anodizing/Magnesium Aluminum Alloy Coating in double sided with 275g/m²
  • Warranty:10-year warranty , 20-year service life



  • Ground solar pv mounting bracket system designs with great flexibility both for commercial and residential roof solar system.
  • WeBright Solar Panel Tracking Mount hihgly engineered solution which can effectively reduce the influence of wind on the solar panel power system, with Q235B steel bracket as main body material,HDG surface treatment, service life is more than 25 years.
  •  Adjustable Solar Panel Mounting Rack Bracket can secure the array without damaging the flat roof. Rail Mounting System is compatible with the usual framed modules and typically does not require roof penetrations.
  •  Ground Mounted Solar Panel Adjustable Mount designed according to the actual installation angle and no need to break the waterproof layer.


Solar PV Mounting System Hardware

Solar Mounting Bracket Package
